SKFBSD 4090 CG參數
| 角接觸推力球軸承 for screw drives, single direction | |||||||||||
| 主要數據尺寸 | 基本負荷額定值 | 疲勞負荷限值 | 可達到的速度 | 體積 | 型號 | ||||||
| 動態 | 靜態 | 當潤滑與 | SKF | SNFA | |||||||
| 油脂 | 滴油潤滑 | ||||||||||
| d | D | H | C | C0 | Pu | ||||||
| mm | kN | kN | r/min | kg | - | ||||||
 | |||||||||||
| 40 | 90 | 20 | 64 | 170 | 6,3 | 6000 | 7000 | 0,68 | BSD 4090 CG | BS 40/90 7P62U | |
SKFAngular contact thrust ball bearings for screw drivesBSD 4090 CG屬于超高精密軸承，它是角接觸推力球軸承 for screw drives, single direction的Angular contact thrust ball bearings for screw drives，內徑：40，外徑：90，厚度20，SKFBSD 4090 CG主要應用于輸送等機械上、等領域。如果您需要購買或者了解更多關于SKFBSD 4090 CG的信息， 歡迎撥打訂購熱線：022-27921004
- SKFBSD 4090 CG近似型號
- SKF BSD 4090 CG 尺寸：40mm × 90 × 20 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKF PWTR 4090.2RS 尺寸：40mm × 90 × 30 類型：滾輪軸承 備注：帶法蘭圈支承滾子
- SKF NUTR 4090 A 尺寸：40mm × 90 × 30 類型：滾輪軸承 備注：帶法蘭圈支承滾子
- SKFBSD 4090 CG相關型號
- SKFBSD 3062 CG 尺寸：30mm × 62 × 15 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBSD 60120 CG 尺寸：60mm × 120 × 20 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBSA 305 CG 尺寸：25mm × 62 × 17 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBEAS 020052-2Z 尺寸：20mm × 52 × 28 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBSA 207 CG 尺寸：35mm × 72 × 17 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBSD 4090 CG 尺寸：40mm × 90 × 20 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBEAS 008032-2Z 尺寸：8mm × 32 × 20 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBEAS 020052-2Z/PE 尺寸：20mm × 52 × 28 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBSA 210 CG 尺寸：50mm × 90 × 20 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBSA 308 CG 尺寸：40mm × 90 × 23 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBSD 4090 CG推薦型號
- NTN 61905 尺寸：25mm × 42 × 9 類型：
- FAFNIR 6214-2RS 尺寸：70mm × 125 × 24 類型：
- SKF 7216B/DB 尺寸：80mm × 140 × 52 類型：
- SKF 7328B/DF 尺寸：140mm × 300 × 124 類型：
- NTN 23256CACK/W33 尺寸：280mm × 500 × 176 類型：
- NTN K30×37×16 尺寸：30mm × 37 × 16 類型：
- NTN NA4828 尺寸：140mm × 175 × 35 類型：
- MAC NU414 尺寸：70mm × 180 × 42 類型：
- NTN NJ2206 尺寸：30mm × 62 × 20 類型：
- SKF 32212BJ2/Q 尺寸：60mm × 110 × 29.75 類型：
