SKFFBSA 208 A/ QBC參數
| 角接觸推力球軸承 for screw drives, cartridge units with flanged housing | |||||||||||
| 主要數據尺寸 | 基本負荷額定值 | 疲勞負荷限值 | 可達到的速度 | 體積 | 型號 | ||||||
| 動態 | 靜態 | 預壓 | SKF | SNFA | |||||||
| A | B | ||||||||||
| d | D2 | A | C | C0 | Pu | ||||||
| mm | kN | kN | r/min | kg | - | ||||||
 | |||||||||||
| 40 | 128 | 106 | 69,275 | 224 | 8,3 | 3150 | 1575 | 10 | FBSA 208 A/ QBC | BSQU 240/1 TDT | |
SKFAngular contact thrust ball bearings for screw drivesFBSA 208 A/ QBC屬于超高精密軸承，它是角接觸推力球軸承 for screw drives, cartridge units with flanged housing的Angular contact thrust ball bearings for screw drives，內徑：40，外徑：128，厚度106，SKFFBSA 208 A/ QBC主要應用于裝卸搬運機械和各類產業機械、等領域。如果您需要購買或者了解更多關于SKFFBSA 208 A/ QBC的信息， 歡迎撥打訂購熱線：022-27921004
- SKFFBSA 208 A/ QBC近似型號
- SKF GEZM 208 ES-2RS 尺寸：63.5mm × 100.013 × 95.25 類型：需維護的徑向球面滑動軸承 備注：鋼對鋼，延長內圈
- SKF BS2-2208-2CS/VT143 * 尺寸：40mm × 80 × 28 類型：球面滾子軸承 備注：圓柱和圓錐孔
- SKF YAR 208-2RF/W64 尺寸：40mm × 80 × 49.2 類型：工程產品 備注：Y-軸承, 含Solid Oil
- SKF 6208-2RS1 * 尺寸：40mm × 80 × 18 類型：深溝球軸承 備注：單列
- SKF YAR 208-2RF/VE495 尺寸：40mm × 80 × 49.2 類型：Y-軸承 備注：帶平頭螺釘鎖定的
- SKF PCZ 1208 M 尺寸：19.05mm × 22.225 × 12.7 類型：復合干式滑動軸套 備注：帶英制尺寸
- SKF YAR 208-2F 尺寸：40mm × 80 × 49.2 類型：Y-軸承 備注：帶平頭螺釘鎖定的
- SKF 6006-2Z/VA208 尺寸：30mm × 55 × 13 類型：工程產品 備注：深溝球軸承, 單列, 用于高溫
- SKF 6208-RZ * 尺寸：40mm × 80 × 18 類型：深溝球軸承 備注：單列
- SKF NU 208 ECJ * 尺寸：40mm × 80 × 18 類型：圓柱滾子軸承 備注：單列
- SKFFBSA 208 A/ QBC相關型號
- SKFFBSA 209/ QFC 尺寸：45mm × 124 × 106 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 207/ QFC 尺寸：35mm × 90 × 86 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 206/ QFC 尺寸：30mm × 80 × 84 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 208/ QBC 尺寸：40mm × 124 × 106 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 205/ QFC 尺寸：25mm × 80 × 82 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 210/ QFC 尺寸：50mm × 124 × 106 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 206 A/ QFC 尺寸：30mm × 88 × 86 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 206/ DB 尺寸：30mm × 80 × 52 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 207/ DF 尺寸：35mm × 90 × 52 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 210 A/ QBC 尺寸：50mm × 128 × 106 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 208 A/ QBC推薦型號
- STEYR 6217-2RS 尺寸：85mm × 150 × 28 類型：
- SNR 7234B 尺寸：170mm × 310 × 52 類型：
- NTN 71914C/DB 尺寸：70mm × 100 × 32 類型：
- GMN 71914C/DT 尺寸：70mm × 100 × 32 類型：
- SKF 7248C/DT 尺寸：190mm × 340 × 110 類型：
- NTN RNA4915 尺寸：75mm × 105 × 30 類型：
- MAC NU232 尺寸：160mm × 290 × 48 類型：
- STEYR NJ2218E 尺寸：90mm × 160 × 40 類型：
- SKF 4204ATN9 尺寸：20mm × 47 × 18 類型：
- SKF NU1021ML 尺寸：105mm × 160 × 26 類型：
