| 角接觸推力球軸承 for screw drives, cartridge units with flanged housing | |||||||||||
| 主要數據尺寸 | 基本負荷額定值 | 疲勞負荷限值 | 可達到的速度 | 體積 | 型號 | ||||||
| 動態 | 靜態 | 預壓 | SKF | SNFA | |||||||
| A | B | ||||||||||
| d | D2 | A | C | C0 | Pu | ||||||
| mm | kN | kN | r/min | kg | - | ||||||
 | |||||||||||
| 35 | 90 | 52 | 36,5 | 98 | 3,65 | 5600 | 2800 | 3,2 | FBSA 207/ DF | BSDU 235 FF | |
SKFAngular contact thrust ball bearings for screw drivesFBSA 207/ DF屬于超高精密軸承，它是角接觸推力球軸承 for screw drives, cartridge units with flanged housing的Angular contact thrust ball bearings for screw drives，內徑：35，外徑：90，厚度52，SKFFBSA 207/ DF主要應用于工程液壓油缸、等領域。如果您需要購買或者了解更多關于SKFFBSA 207/ DF的信息， 歡迎撥打訂購熱線：022-27921004
- SKFFBSA 207/ DF近似型號
- SKF HA 207 尺寸：30.163mm × 35 × 29 類型：軸承附件 備注：用于英制軸的緊定套
- SKF NU 207 ECM * 尺寸：35mm × 72 × 17 類型：圓柱滾子軸承 備注：?jiǎn)瘟?/dd>
- SKF YAT 207 尺寸：35mm × 72 × 33 類型：Y-軸承 備注：帶平頭螺釘鎖定的
- SKF 5207 E-2RS1 尺寸：35mm × 72 × 27 類型：角接觸球軸承 備注：雙列
- SKF 6207/VA201 尺寸：35mm × 72 × 17 類型：深溝球軸承 備注：用于高溫的深溝球軸承
- SKF 6207-2ZNR * 尺寸：35mm × 72 × 17 類型：深溝球軸承 備注：?jiǎn)瘟?，帶止?dòng)環槽
- SKF 2207 ETN9 尺寸：35mm × 72 × 23 類型：自調心球軸承 備注：圓柱孔和圓錐孔
- SKF YAR 207-2RF/HV 尺寸：35mm × 72 × 42.9 類型：Y-軸承 備注：帶平頭螺釘鎖定的
- SKF NU 2207 ECML * 尺寸：35mm × 72 × 23 類型：圓柱滾子軸承 備注：?jiǎn)瘟?/dd>
- SKF YAR 212-207-2FW/VA228 尺寸：61.913mm × 110 × 65.1 類型：Y-軸承 備注：用于高溫
- SKFFBSA 207/ DF相關型號
- SKFFBSA 206/ QFC 尺寸：30mm × 80 × 84 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 205/ QFC 尺寸：25mm × 80 × 82 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 208/ DF 尺寸：40mm × 124 × 66 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 208 A/ QBC 尺寸：40mm × 128 × 106 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 204/ DB 尺寸：20mm × 60 × 47 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 208 A/ QFC 尺寸：40mm × 128 × 106 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 210/ DF 尺寸：50mm × 124 × 66 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 207/ DF 尺寸：35mm × 90 × 52 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 212 A/ QFC 尺寸：60mm × 145 × 114 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 210 A/ QBC 尺寸：50mm × 128 × 106 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 207/ DF推薦型號
- SKF 60/500 尺寸：500mm × 720 × 100 類型：
- MRC 71901C 尺寸：12mm × 24 × 6 類型：
- NTN 7003AC 尺寸：17mm × 35 × 10 類型：
- SNR 7312AC/DF 尺寸：60mm × 130 × 62 類型：
- DKF 7230B/DF 尺寸：150mm × 270 × 90 類型：
- SKF 21308CCK 尺寸：40mm × 90 × 23 類型：
- NTN NA6902 尺寸：15mm × 28 × 23 類型：
- SKF 812/560 尺寸：560mm × 750 × 150 類型：
- SKF NJ206E 尺寸：30mm × 62 × 16 類型：
- KOYO NF330 尺寸：150mm × 320 × 65 類型：
